SPECI F ICATION SHEET The Consistant Pursuit of Gains in Protection C O R S A I R - X R C C O R S A I R - X C O N T O U R - X Q U A N T U M - X S I G N E T - X R E G E N T - X R A M - X C L A S S I C - V X D - 4 V X - P R O4
Full Face Open Face Off Road CORSAIR-X RC QUANTUM-X CORSAIR-X SIGNET-X RAM-X COUTOUR-X CLASSIC-V REGENT-X VX-PRO4 CONTOUR-X 7 Intake ports / 6 Exhaust ports REGENT-X 5 Intake ports / 6 Exhaust ports Air Channel Enhanced air exhaust from the eyeport area, connected via a dedicated air channel to the side cowl vent. Applicable only for CORSAIR-X. CORSAIR-X RC CORSAIR-X 6 Intake ports / 7 Exhaust ports QUANTUM-X SIGNET-X 5 Intake ports / 6 Exhaust ports CLASSIC-V 2 Exhaust ports RAM-X 5 Intake ports / 7 Exhaust ports VX-PRO4 6 Intake ports / 8 Exhaust ports XD-4 7 Intake ports / 7 Exhaust ports XD-4 1 2
CORSAIR-X RC CORSAIR-X QUANTUM-X SIGNET-X RAM-X CONTOUR-X CLASSIC-V REGENT-X XD-4 VX-PRO4 Carbon Fiber Composite Exclusive technology developed internally by Arai for the GP-6RC F-1 helmet. The RC models utilize carbon fiber found in the latest generation of commercial airlines, bonded with Arai´s proprietary resins and is reinforced with a band of incredibly strong fibers specifically oriented to disperse energy loads laterally across the shell surface. This band increases shell strength without adding thickness or weight, and allows the use of a thinner EPS liner which greatly enhances the upward field of view. The new Peripherally Belted-Super Complex Laminate Construction shell design combines multiple materials and techniques created internally by Arai that deliver both performance and affordability. Created from super fiber and special synthetic fibers, and assembled by Arai experts, the shell provides both superb tensile strength and flexibility characteristics. Like the metal bands used to hold a wooden barrel together, a variety of carefully placed materials, combined with newly developed resins result in strong shells with less weight. PB-ScLc² Peripherally Belted Super Complex Laminate Construction-II PB-SNC² Peripherally Belted Structural Net Composite-II The Peripherally Belted Complex Laminate Construction with latest generation Z resin and AR Mat is the accumulation of years of Arai´s experience in shell making, handmade with over 25 individual pieces bound by Arai´s new proprietary resin and reinforced by the Peripheral Belt. PB-cLc² Peripherally Belted Complex Laminate Construction-II The Peripherally Belted Complex Laminate Construction shell features a newly developed AR MAT which allows the Regent-X to achieve a lower cost without compromising weight or protection performance. PB-cLc¹ Peripherally Belted Complex Laminate Construction-I The Peripherally Belted Complex Laminate Construction reinforces Arai´s cLc shell for more strength and weight reduction adding more to Arai´s accumulation of incremental improvements over decades of experience to pursue gains in protection. PB-cLc Peripherally Belted Complex Laminate Construction *Image of CORSAIR-V RC shell shown Shell Construction 3 4
INTERMEDIATE OVAL Slightly longer front to back than Round Oval. ROUND OVAL Very close to a pure round shape with a slight increase in length from front to back. LONG OVAL Longer front-to-back and a little thinner side-to-side than Intermediate Oval. REGENT-X *After removing 5mm Peel-Away Side-Temple Pads RAM-X *After removing 5mm Peel-Away Side-Temple Pads CLASSIC-V XD-4 *After removing 5mm Peel-Away Side-Temple Pads VX-PRO4 *After removing 5mm Peel-Away Side-Temple Pads CONTOUR-X *After removing 5mm Peel-Away Side-Temple Pads QUANTUM-X *After removing 5mm Peel-Away Side-Temple Pads *By replacing the Round Oval Head Liner with the CORSAIR-X Head Liner. CORSAIR-X RC / CORSAIR-X *After removing 5mm Peel-Away Side-Temple Pads *After removing 5mm Peel-Away Side-Temple Pads SIGNET-X *See Micro-Fit Interior on page 7 Head Shapes CORSAIR-X RC CORSAIR-X QUANTUM-X SIGNET-X CONTOUR-X REGENT-X Interior Materials Odor Resistant New exclusive liner with Odor resistant material stays fresher between cleanings. Brushed Nylon Soft, smooth and plush, yet durable, Brushed Nylon offers a balance of all the desirable qualities necessary in a helmet lining material. *The Brushed Nylon in the CONTOUR-X also features the Odor Resistant properties found in the CORSAIR-X. XD-4 VX-PRO4 Dry CoolTM Arai´s Dry-CoolTM material transfers heat and moisture away from the rider quickly and efficiently. RAM-X CLASSIC-V Odor Resistant New exclusive liner with Odor resistant material stays fresher between cleanings. Open Face Open Face Off Road Off Road Full Face Full Face 5 6
Not Applicable CORSAIR-X RC CORSAIR-X CONTOUR-X QUANTUM-X SIGNET-X REGENT-X RAM-X XD-4 VX-PRO4 CLASSIC-V Micro Fit Interior CORSAIR-X RC CORSAIR-X CONTOUR-X QUANTUM-X SIGNET-X REGENT-X XD-4 VX-PRO4 RAM-X CLASSIC-V Sound Absorbing Ear Pad Foam Not Applicable CORSAIR-X RC CORSAIR-X QUANTUM-X SIGNET-X RAM-X XD-4 VX-PRO4 CONTOUR-X REGENT-X CLASSIC-V Micro Fit Cheekpads Not Applicable CORSAIR-X RC CORSAIR-X QUANTUM-X SIGNET-X RAM-X XD-4 VX-PRO4 CONTOUR-X REGENT-X CLASSIC-V Removable Cheek Pads Removable Head Liners Head liners are easily removable by gently pulling the four yellow snaps in each corner. The head liner has 5mm temple pads in the side pockets which can be removed for easy micro fitting. The REGENT-X head liner is held by hook-and-pull patches in the front, and tabs that slide behind the EPS liner in the back and are held in by the cheek pads. The REGENT-X head liner also has removable 5mm temple pads in the side pockets for easy micro fitting. The tongue tab on the back of the cheek pad slides behind the EPS liner, then the front tab clicks into a receiver in the chin liner. The cover is removable for easy washing. Snap-in Head Liners Hook-and-Pull Head liner Forward Fit Cheek Pads The tongue tab on the front of the cheek pad slide behind the chin liner, and the back presses against the EPS liner. The cover is removable for easy washing. Reverse Fit Cheek Pads Studs on the ear cups snap into a receiving plate in the helmet. Snap-in Ear Cups Giving even more ability to craft the perfect fit and comfort, the cheekpads now feature a 5mm peel away layer for added room if needed. Arai´s peel-away temple crown pads give the option of 5mm more interior width* if needed. *See fitting details in Head Shapes on page 5. The cheek pads of these 8 models have molded pockets for speakers providing a more comfortable fit. A layer of foam in the ear pocket to help prevent noise from reaching the riders ears. *Except for REGENT-X and Open Face models. 7 8
VAS Latch Shield Pro Shade System Helps minimize wind noise and also aids with the extraction of hot air from the face area. Provides additional deflection of road debris away from neck. CORSAIR-X RC CORSAIR-X CONTOUR-X QUANTUM-X SIGNET-X REGENT-X RAM-X XD-4 Fixed Air Spoiler Not Applicable CORSAIR-X RC CORSAIR-X QUANTUM-X SIGNET-X XD-4 CONTOUR-X REGENT-X RAM-X CLASSIC-V VX-PRO4 Pull Down Air Spoiler Optional Not Applicable Not Applicable CORSAIR-X RC CORSAIR-X CONTOUR-X QUANTUM-X SIGNET-X REGENT-X RAM-X CLASSIC-V XD-4 VX-PRO4 Not Applicable CORSAIR-X RC CORSAIR-X CONTOUR-X QUANTUM-X SIGNET-X REGENT-X RAM-X CLASSIC-V XD-4 VX-PRO4 CORSAIR-X RC CORSAIR-X QUANTUM-X SIGNET-X CONTOUR-X REGENT-X RAM-X CLASSIC-V XD-4 VX-PRO4 ES Chin Cover VAS-V MV Shield VAS-Z Shield TX-XD Shield VAS Max Vision shield is standard to provide better visibility in all seasons and for all types of riding. A clear Pinlock insert is standard with the CORSAIR-X RC, CORSAIR-X, QUANTUM-X, SIGNET-X, AND CONTOUR-X. A dual-function lever releases both the side cover / pod and shield pin for quick and simple shield removal. Being able to see the shield mechanism allows for easier shield changes. Based on the VAS-V shield, the VAS-Z shield also utilizes a dual-function lever to release both the side cover/pod and shield for quick and simple shield removal. The Pinlock lens comes standard with the RAM-X. Light and versatile, the TX-XD shield is excellent in street riding and off-road applications giving the rider a wide field of view. The TX-XD Shield also comes in anti-fog laminated variants in Clear, Light Tint, and Dark Tint. The Pinlock lens forms a seal between the inside of the face shield and rider to mitigate fogging. The optional Pro Shade System not only offers a quick, convenient shade to block ambient light, but also the benefit of an aerodynamic peak to block sudden bursts of light when cresting a hill, rounding a canyon bend, or exiting a tunnel with just a subtle dip of the head, allowing rider´s hands to stay right where they need to be. The Pro Shade System comes installed on a MAX-V Brow Vented shield, providing an excellent field of view and maintaining the benefits of Arai´s Brow Vent intake ducts. The optional clear MAX-V BV Pinlock anti-fog insert reduces fogging without reducing your field of view. The VAS latch captures and holds the shield securely closed to help prevent unexpected opening. In addition to the de-mist function, the larger latch allows for an intuitive and seamless shield operation. VAS-V Pinlock Lens VAS-Z Pinlock Lens VAS-Z Type VAS-V Type The new chin cover accentuates the egg-shaped form of the outer shell. In addition, it blocks the intrusion of turbulent air from the underside of the helmet and increases negative pressure to enhance the function of the chin vent by drawing more air from the mouth area. 9 10
www.AraiAmericas.com © Arai Helmet, Inc. 2023, Printed 01/23 in USA. Specifications subject to change without notice. *HCM (Head Circumference Measurement) should be a starting point only in determining your helmet size. Determining the best possible fit should be from actual test fittings of Arai´s various interior fit packages. Changes and updates can affect the standard pad thickness supplied with your helmet. INTERIOR LINING THICKNESSES CHEEK PAD THICKNESSES OPTIONAL STANDARD / size Lining Code XS I HCM(cm) (53-54) S II (55-56) M III III (57-58) L IV (59-60) XL V (61-62) XXL (63-64) size Lining Code XS I HCM(cm) (53-54) S II (55-56) M III III (57-58) L IV (59-60) XL V (61-62) XXL (63-64) CORSAIR-X RC 12 mm 10 mm 7 mm 5 mm CORSAIR-X 12 mm 10 mm 7 mm 5 mm CONTOUR-X/REGENT-X 12 mm 10 mm 7 mm 5 mm RAM-X QUANTUM-X/SIGNET-X 12 mm 10 mm 7 mm 5 mm XD-4 12 mm 10 mm 7 mm 5 mm VX-PRO4 12 mm 10 mm 7 mm 5 mm size XS HCM(cm) (53-54) S (55-56) M (57-58) L (59-60) XL (61-62) XXL (63-64) CORSAIR-X RC CORSAIR-X CONTOUR-X/REGENT-X QUANTUM-X/SIGNET-X Thicker Thinner 30 - 30 25 20 - 20 - 20 15 12 - 25 - 25 20 15 - Standard (mm) 30 30 30 25 25 20 Thicker 20 20 20 15 15 - Thinner 25 25 25 20 20 15 Standard (mm) 30 30 30 25 25 20 Thicker 20 20 20 15 15 - Thinner 25 25 25 20 20 15 Standard (mm) RAM-X VX-PRO4 30 30 30 25 30 25 Thicker 20 20 20 15 20 15 Thinner 25 25 25 20 25 20 Standard (mm) XD-4 25 25 25 20 20 15 Thicker 15 15 15 12 12 - Thinner 20 20 20 15 15 12 Standard (mm) 30 30 35 30 30 30 Thicker 20 20 25 20 20 20 Thinner 25 25 30 25 25 25 Standard (mm) CLASSIC-V 30 30 30 25 25 20 Thicker 20 20 20 15 15 12 Thinner 25 25 25 20 20 15 Standard (mm) size XS HCM(cm) (53-54) S (55-56) M (57-58) L (59-60) XL (61-62) XXL (63-64)
